MASTER BAG 300X
High-Performance Square Bottom Paper Bag Machine
The Master Bag 300X is an advanced roll-fed square bottom paper bag machine engineered for high-volume, precision manufacturing. Designed for the food industry, retail packaging, and professional paper bag producers, this machine delivers reliable production of durable, eco-friendly paper bags without handles.
Combining intelligent automation with high-precision engineering, the Master Bag 300X ensures efficient production, consistent quality, and reduced operating costs.
Why the Master Bag 300X Stands Out
Fully Automated Production
The machine integrates paper feeding, tube forming, cutting, and bottom forming into a continuous automated process, minimizing labor requirements and maximizing operational efficiency.
High Precision & Accuracy
A photoelectric detection system ensures every bag is produced with precise dimensions and consistent quality, even when processing thin paper materials.
Advanced Motion Control
Equipped with Japanese YASKAWA servo motors, the system provides stable machine performance, smooth motion control, and consistent high-quality output.
Key Machine Features
Paper Roll Feeding & Conveyance
Roll-fed system with automatic lifting for quick roll replacement
Air shaft unwind system with hydraulic lifting control
Automatic tension control for stable and consistent paper feeding
Paper Bag Forming
Precision gluing and tube forming system
Accurate four-corner square bottom forming
Clean and reliable adhesive application
Finished Bag Collection
Smooth pressing and conveying of finished bags
Automatic counting system for easy packaging and inventory management
Bags ready for collection or further downstream processing
技术规格
Specification Details
Bag Dimensions (L × W × Bottom) 280–530 mm × 150–330 mm × 70–180 mm
Paper Thickness 60–150 gsm
Maximum Production Speed Up to 200 bags per minute
Paper Roll Width 470–1050 mm
Paper Roll Diameter Up to 1500 mm
Machine Power 380V – 8 kW
Machine Weight 8,000 kg
Machine Dimensions 9.5 × 2.6 × 1.9 meters
Key Benefits
? High-speed production for industrial paper bag manufacturing
? Stable and precise performance with advanced servo control
? Reduced downtime with roll-fed automatic paper feeding
? Consistent quality for food and retail packaging
? Supports sustainable kraft paper packaging to replace plastic bags
Ideal Applications
The Master Bag 300X is perfectly suited for:
Flour mills and food packaging companies
Retail packaging manufacturers
Paper bag production factories
Businesses transitioning from plastic to sustainable paper packaging
Upgrade Your Paper Bag Production
The Master Bag 300X combines efficiency, precision, and sustainability in a single high-performance machine — helping manufacturers increase productivity while meeting modern environmental standards.
Explore the Master Bag 300X and take your packaging production to the next level.
