MASTER BAG DLS 200

Description:

MASTER BAG DLS 200 was developed by Gutenberg, as a highly- reliable machine featuring the latest control technology.
The machine is ideal for medium-sized packaging for the food industry, whether single or double-layer. This machine provides the basis for stable and reliable production.
Naturally, the MASTER BAG DLS 200 can be equipped with various additional devices as well as an inline printer to meet customer-specific needs

with HDPE film coated or 2-layers paper
Robatech hot melt glue machine for bag sealing,
plastic window including
Paper bag width (W) 150-330mm
Paper bag bottom width (H) 70-180mm
Paper thickness 60-150g/m2
Max. Paper bag speed 150-200pcs/min
Paper roll width 380-1050mm
Max. Paper roller diameter 1200mm
Paper roller inner diameter 76mm
Air supply 0.6-1.2Mpa
Air consumption 0.12m3/min
Power 15 KW
Weight 8500 KGS
Power 3 phases, 380V±10%, 50 Hz
Compressed Air pressure: 0.6 MPa
volume: approx. 0.5 m3/h
oil and humidity: ?8 mg/m3
Category
Bag Making
Manufacturer
Gutenberg
Model
MASTER BAG DLS 200
Year
2022
