HEIDELBERG SM102-5 AGE 2000 Sheet-fed offset press Straight High delivery Speed 15.000 sheet/h Max paper size 720 x 1020 mm Min paper size 280 x 420 mm Dimensions (LxWxH): 8,70 x 3,00 x 2,17mt. -Steel plate on feeder and delivery with ramp •? ?Preloader •? ?Stream feeder Ultrasonic double-sheet detection •? ?Electronic side lay control •? ?Alcolor continuous dampening system with Technotrans's alcohol metering; Delta D •? ?Preset Feeder •? ?CP 2000 Machine control and diagnosis by plasma monitor console /self-diagnostic, control and monitor console; remote inking; -dampening; axial, circumferential, •? ?Autoplate (semi-automatic plate loader) •? ?preset link •? ?Air-cooled •? ?Powder sprayer device Grafix Exatronic •? ?Oil drip pan,
Net Weight 34,730 kg Length 1,010 cm Width 331 cm Height 217 cm Format Max X 72 cm Format Max Y 102 cm Format Min X 28 cm Format Min Y 42 cm Printing Surface X 70 cm Printing Surface Y 102 cm Max. Paper Strength 0.8 mm Min. Paper Strength 0.03 mm Stacking Height Feeder 123 cm Stacking Height Delivery 121 cm
